High Quality

• Easily changeable control version
• Special solenoid is designed for strength and long life and guarantees a lifetime operating for at least 1,000,000 times.
• Bond sensor output
• For single and double swing doors
• Automatic and manual
• The Electromechanical Lock is easily changed between failsafe and fail-secure modes.
• Slim lock body can be flush mounted directly into metal such as door mullions.
• The electromechanical Lock is very lightweight. 25 mm wide faceplate is designed for installation in virtually all types of doors and frames. The rectangular shaped and arc-shaped faceplates are used to suit the different users' habits of installations.
• Operating Voltage: ML-300: 12 or 24 VDC
• ML-300-SW:12~24VDC/AC
• Current Draw: ML-300: 280mA/12 VDC; 140mA/24VDC
• ML-300-SW: 210mA/12VDC; 150mA/24VDC
• Version Changeable: Fail-safe/secure changeable
• Operating Temperature: ?10~45?C
• Humidity: 0~95% non-condensing
• Lock bolt sensor switch output:
• SPDT rated 3/125VAC Backset : 30mm
• Net Weight: ML-300: 800g / ML-300-SW: 815g
• Only applicable to vertical installation Cylinder not included
