MCM Single Bolt Lock 801 SN Made in Spain
MCM Single Bolt Lock 801 SN Made in Spain
Couldn't load pickup availability
Get Aed 20 off when you spend Aed 1,000 or more! Learn more
Specifications
Specifications
High Quality
Lock Type Single Point,
Operation Type Handle Operated, Cylinder Operated
Locking Elements Deadbolt & Latch
Locking Type European Profile Cylinder
Recommended Cylinder BPS
Key Turns 3
Number of Keys 5
Case Dimensions (mm) Height 170 x Depth 112 x Thickness 21
Backset Inc Forend (mm) 70
Interaxis (mm) 85
Follower Type Standard Follower
Follower (mm) 8
Forend Dimensions (mm) Length 240 x Width 28.0 x Thickness 3
Forend Shape Flat
Case Steel, Galvanised
Forend Material: Steel, Finish: Painted Silver, Painted Gold
Reversible Latch Yes
Adjustable Latch 12mm-17mm
Latch Throw (mm) 12
Deadbolt Operation Standard
Deadbolt Throw (mm) 37
Net Weight (kg) 2.3
Boxed Quantity 1
Industrial Packaging Quantity 10
Standard Packaging Box
Product Details
Product Details
Security Level :
IMPA Code :
HSN Code :
Packing Details :
Hand Side :
Recommended use :
Suitable for :
