Description
xTechnical features
| Door Type | Wooden Doors |
| Lock Application Type | Mortise Lock |
| Operation Type | Handle Operated, Cylinder Operated |
| Locking Points | 3 points |
| Locking Type | European Profile Cylinder |
| Closing Mechanism | Step Mechanical |
| Locking Elements | Deadbolt & Latch |
| Multi Point Type | Long Forend |
| Deadbolt Operation | Standard |
| Reversible Latch | Yes |
| Compatible with Electric Strike | Yes |
Configuration
| Number of Keys | 5 |
| Key Material | Brass Nickel |
| Interaxis (mm) | 85 |
| Backset Inc Forend (mm) | 65 |
| Backset Without Forend (mm) | 62 |
| Case Height (mm) | 170 |
| Case Depth (mm) | |
| Case Thickness (mm) | 14 |
| Case Material | Steel |
| Case Finish | Galvanised |
| Additional Locking Point Material | Nickel Zamak |
| Deadbolt Shape | Rectangular |
| Deadbolt Material | Nickel Zamak |
| Deadbolt Dimension | 53x10 |
| Deadbolt Throw (mm) | 37 |
| Latch Dimension | 27x15 |
| Latch Throw (mm) | 12 |
| Latch Material | Nickel Zamak |
| Follower Type | Standard Follower |
| Follower (mm) | 8 |
| Material of the Follower | Zamak |
| Forend Shape | U-Shape |
| Forend Length (mm) | 2030 |
| Forend Thickness (mm) | 3 |
| Forend Material | Steel |
| Forend Finish | Painted Gold |
| Security Escutcheon Included | Yes |
| Strike Plate Included | Yes |
| Escutcheon Included | Yes |
